Powerdaylight Ø 53 cm Eco Cradle round system with flat roof flashing
Powerdaylight Round ECO Cradle System - flat roof flashing
The Powerdaylight Cradle is a light tube that is suitable for a flat or slightly sloping roof. The Powerdaylight daylight tube captures the daylight through a flat glass panel and transports it inside using a highly reflective tube.
The ECO version of the Powerdaylight Cradle is an extra insulated variant of the standard Cradle system. The flat glass panel is fitted with low-emission glass, the air chamber of which is filled with argon gas. The system achieves an insulation value of 0.74W/m²K, making this version suitable for passive construction.
The Powerdaylight daylight system is equipped with the following as standard:
- A flat glass panel made of toughened glass, which gives it impact and scratch resistance.
- A ‘Powerdaylight Cell’ reflective grid integrated within the flat glass panel which captures daylight and reflects it down into reflective tube.
- Reflective aluminum tubing which has an internal silver surface treatment with a specular reflection of up to 98%.
The Powerdaylight brand is aware of the potential of reusing materials and makes a conscious choice not to use plastic. Powerdaylight systems are manufactured from materials such as glass and aluminium which are 100% recyclable and sustainable.
| ETIM | EC003113 Daglichtsysteem |
|---|---|
| Laminated Security Glass | No |
| Maximum standard length | 43 cm |
| Advies maximale verlenging | Maximaal 15 meter |
| Product guarantee | 10 years |
| Country of Manufacture | Spain |
| Maximale puntlast | 12 KG |
| Totaal draagvermogen | 150 KG /m2 |
| Doorvoer van zonne-energie (EN 410) | g‐value zomer = 0.62 / g‐value winter = 0.77 |
| Warmtedoorgangscoëfficiënt compleet systeem | U =0,74 W/m 2 K |
| SCRATCH RESISTANCE | 6,5 Mohrs |
| Kleurweergave-index | CRI = 100 |
| Geluidsisolatiewaarde (EN ISO 717‐1) | 30 dB |
