Powerdaylight Ø 35 cm pitched roof ventilation set black

Powerdaylight Ø 35 cm pitched roof ventilation set black

This ventilation set is suitable for bathrooms, toilets, and kitchens.

Fully compliant with the Building Decree, the ventilation set meets the required ventilation capacity for the kitchen (75 m³/h), bathroom (50 m³/h), and toilet (25 m³/h).

Natural ventilator
The basic roof duct forms the basis of the Powerdaylight ventilation system.
Its unique feature is that it promotes ventilation 24 hours a day.
Air is extracted from the home in virtually all weather conditions. The solution for moisture problems in existing homes. The above-roof section of the roof duct is equipped with a smart design: a collection system that prevents condensation from flowing back into the ventilation duct. After the cooled air condenses in the duct, the moisture is discharged outside.

Mechanical Fan
The roof duct (outside the roof) includes a fan for additional ventilation when needed.

As the fan is positioned outside the home, the air intake is maximised while the noise is minimised!

Technical Specifications

Fan flow rate in operation: minimum 75 m³/hour.
Fan electrical specifications: 230 V - 50/60 Hz - 18 Watt
IP 55 according to EN 60529.
Wiring: 2 x 0.5 mm² with a length of 2000 mm
